DNH HP-6 6W plastic miniature loudspeaker
Technical Specification
- Make: DNH
- Model code: HP-6
- Power output: 6 W
- Operating temperature: -40 ~ +110 °C
- Protection: IP67
This 6W plastic miniature loudspeaker is marine grade IP67 weatherproof rated. Suitable for outdoor and indoor installation. EN 45545-2 compliant.
Read more| Make | DNH |
|---|---|
| Manufacturer | DNH A/S |
| Category | Navigation, communication and electronics>Public address and general alarm systems (PA/GA) |
| Model code | HP-6 |
| Power output | 6 W |
| Operating temperature | -40 ~ +110 °C |
| Protection | IP67 |
Product description
DNH HP-6 Loudspeaker
The DNH HP-6 is a high-performance loudspeaker designed for industrial and commercial environments, featuring robust construction and exceptional acoustic capacity. Crafted for durability, all external hardware is made from stainless steel, ensuring reliability even in challenging conditions. This model meets stringent ISO 9001 certification standards, affirming its superior quality.
Technical Features
- Material: The HP-6 is constructed from polyamide UL94 V0, finished in RAL 7035, providing excellent resistance to wear and weather elements.
- Sound Pressure Levels: This speaker offers a sound pressure level of 100 dB with 1W/1m and can reach up to 107 dB at rated power, ensuring clear and intense audio output.
- Frequency Range: Operating effectively within a frequency range of 300 – 20000 Hz, it guarantees a broad and high-fidelity sound spectrum.
- Dispersion: The speaker provides a wide dispersion angle of 178° at 1kHz, narrowing to 62° at 4kHz, facilitating versatile sound direction control.
Ideal Use Cases
The HP-6 is meticulously designed for environments that demand robust audio solutions, such as marine and heavy industrial installations. With an IP rating of 67 and an operational temperature range from -40°C to 110°C, it stands up to harsh maritime climates and high-temperature settings. Whether mounted on walls or ceilings, it remains adaptable and effective, adjusting easily with a supplied bracket and cable.
