SCM Sistemas Maritime Telephones & Intercoms  (12)

Head-chest microphone for connection with: JACK - 1 (jack box) Allows hands-free conversation Suitable for being stored in a stowage box Cable length: 6 meters (2 twisted pair) Talk/listen switch: push-button type Used by the Spanish Army (NATO Code 6071/193B) Operating temperature. -20ºC to +50ºC Microphone adjustment. By ajustable arms Relative humidity.  Hasta 95% (no condensada) Chest adjustment.  By ajustable arms Weight. 1.5 Kg aprox. NATO Code. 6071/193B

 Excellent speech quality 12 extensions selector switch (extending up to 24) Portable sound-powered telephone For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Available headphone connection for noisy areas: Model: TA-ACM-A Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC to +70ºC Acoustic alarm. 80 dB(A) (1 m) Relative humidity.  Hasta 95% (no condensada) Assembly. Portable

Excellent speech quality Single extension sound-powered portable telephone For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Available headphone connection for noisy areas:  Model: TA-ACM-A Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC to +70ºC Acoustic alarm. 80 dB(A) (1 m) Relative humidity.  Hasta 95% (no condensada) Assembly. Portable

Excellent speech quality 16 extensions selector switch  For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Available headphone connection for noisy areas: Model: TA-ACM-A Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC+70º  Acoustic alarm.  80 dB(A)(1m) Relative humidity. Up to 95% (non condensing)

Excellent speech quality 12 extensions selector switch (extending up to 24) For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Available headphone connection for noisy areas:  Model: TA-ACM-A Optional acoustic/luminous alarm via relay box ncludes metalic cableglands and springs Other features: earpiece-lock system Includes dampers (VIBCABLE V3CA8010 series) High deflection in all directions Natural frequency between 5 Hz /25 Hz Compliant with MIL-STD-167 Operating temperature. -20ºC to +50ºC Acoustic alarm. 80 dB(A) (1 m) Relative humidity.  Hasta 95% (no condensada)

Handset holder for telephone

Excellent speech quality Material: ABS polymer (fireproof) Spiral cord (1.5 m) Built-in Talk/listen push-button

Excellent speech quality 12 extensions selector switch (extending up to 24) For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Includes headphone connector for noisy areas: Model: TA-ACM-A Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC+70º  Acoustic alarm.  104 dB(A)(1m) Relative humidity. Up to 95% (non condensing)

Excellent speech quality 12 extensions selector switch (extending up to 24) For use on open air deck areas and bridge wings  Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC to +70ºC Acoustic alarm. 80 dB(A) (1 m) Relative humidity.  Hasta 95% (no condensada) Assembly. Mamparo

Excellent speech quality Single way sound-powered telephone For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS plolymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Includes headset connector for noisy areas Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC+70º  Acoustic alarm.  80 dB(A)(1m) Relative humidity. Up to 95% (non condensing)

Excellent speech quality Single way  sound-powered telephone For use on open air deck areas and bridge wings Material: ABS polymer (fireproof) Earpiece: ABS polymer (fireproof) Spiral cord (60 cm extensible to 1.5 m) Optional acoustic/luminous alarm via relay box Includes metalic cableglands Operating temperature. -20ºC to +70ºC Acoustic alarm. 80 dB(A) (1 m) Relative humidity.  Hasta 95% (no condensada) Assembly. Mamparo

Excellent speech quality 12 extensions selector switch (extending up to 24) Acoustic and luminous alarms incorporated Suitable for high-noise level areas Waterproof housing Noise compensated microphone Painted according to military specifications Earpiece: ABS plastic (fireproof) Spiral cord (60 cm extensible to 1.5 m) Available headphone connection for noisy areas: Model: TA-ACM-A  Operating temperature. -20ºC+50º  Acoustic alarm.  104 dB(A)(1m) Luminous alarm. 21W-90 flash/min Alarms supply. 24 VDC-25W Relative humidity. Up to 95% (non condensing) Assembly. Bulkhead
